Valumax™ Autotrol Water Softeners
VALUMAX 255/740, 255/742, 255/760, 255/762
Standard Features (All Units)
• Composite media tank• Heavy duty blowmolded brine tank
• Full 3/4” flow throughout system
• Upper distributor basket
• CSA B483.1
• 8% crosslink resin
• 2310 Brine safety float with #500 aircheck
• 12VAC UL/CSA electrical system with 12’ cord
• 5 year warranty on control
• 10 year warranty on composite media tank
• Install parts (bypass valve, tube adapter kits, drain fittings) are not included with units. These must be ordered separately and are listed at the end of this section.
• Units up to 2 cubic feet (12” x 52” media tank) are shipped with media loaded. Larger systems have media packaged separately which must be loaded on site.
255 Logix Control Valve
• 15.5 GPM continuous service flow; 6 GPM maximum backwash
• Time-tested Duraflow flapper provides frictionless sealing for longer service life
• Fiber-reinforced polymer valve body for superior strength and durability, non-corrosive, and UV-resistant
• Optical sensor for precision cycle positioning
• Designed with double backwash for reduced hardness leakage
• Fully adjustable 5 or 8 cycle control for efficient and reliable water treatment system
• Super capacitor for keeping time of day during power outage
• Programming stored in memory and will not be lost due to power outage
• Large LCD display for easy setup
• History data for valve performance
Call for Other Sizes and Configurations
Valumax 255/740 Logix - Electronic Clock Control | |
Description | Part # |
.75CUFT; 24K; 255-740; RT8X44; BT14X34 | CVM-.75-740 |
1.0CUFT; 30K; 255-740; RT9X48; BT14X34 | CVM-1.0-740 |
1.5CUFT; 45K; 255-740; RT10X54; BT14X34 | CVM-1.5-740 |
2.0CUFT; 60K; 255-740; RT12X52; BT14X34 | CVM-2.0-740 |
3.0CUFT; 90K; 255-740; RT14X65; BT18X40 | CVM-3.0-740 |
Valumax 255/742 Logix - Electronic Clock Control | |
Description | Part # |
.75CUFT; 24K; 255-742; RT8X44; BT14X34 | CVM-.75-742 |
1.0CUFT; 30K; 255-742; RT9X48; BT14X34 | CVM-1.0-742 |
1.5CUFT; 45K; 255-742; RT10X54; BT14X34 | CVM-1.5-742 |
2.0CUFT; 60K; 255-742; RT12X52; BT14X34 | CVM-2.0-742 |
3.0CUFT; 90K; 255-742; RT14X65; BT18X40 | CVM-3.0-742 |
Valumax 255/760 Logix - Electronic Metered Control | |
Description | Part # |
.75CUFT; 24K; 255-760; RT8X44 BT 14X34 | CVM-.75-760 |
1.0CUFT; 30K; 255-760; RT9X48; BT14X34 | CVM-1.0-760 |
1.5CUFT; 45K; 255-760; RT10X54; BT14X34 | CVM-1.5-760 |
2.0CUFT; 60K; 255-760; RT12X52; BT14X34 | CVM-2.0-760 |
3.0CUFT; 90K; 255-760; RT14X65; BT18X40 | CVM-3.0-760 |
Valumax 255/762 Logix - Advanced Electronic Metered Control | |
Description | Part # |
.75 CUFT; 24K 255-762; RT8X44 BT 14X34 | CVM-.75-762 |
1.0CUFT; 30K; 255-762; RT9X48; BT14X34 | CVM-1.0-762 |
1.5CUFT; 45K; 255-762; RT10X54; BT14X34 | CVM-1.5-762 |
2.0CUFT; 60K; 255-762; RT12X52; BT14X34 | CVM-2.0-762 |
3.0CUFT; 90K; 255-762; RT14X65; BT18X40 | CVM-3.0-762 |
Valumax Cabinet 255/760 255/762 Logix - Electronic Metered Control | |
Description | Part # |
0.50CUFT; 15K; WS CAB; 255-760; RT10X18 | CVM-WSCAB-.50-760 |
1.0CUFT; 30K; WS CAB; 255-760; RT10X35 | CVM-WSCAB-1.0-760 |
1.25CUFT; 40K; WS CAB; 255-760; RT12X35 | CVM-WSCAB-1.25-760 |
0.50CUFT; 15K; WS CAB; 255-762; RT10X18 | CVM-WSCAB-.50-762 |
1.0CUFT; 30K; WS CAB; 255-762; RT10X35 | CVM-WSCAB-1.0-762 |
1.25CUFT; 40K; WS CAB; 255-762; RT12X35 | CVM-WSCAB-1.25-762 |
Valumax 255/764 Logix Twin (Two sets of install parts required) | |
Description | Part # |
0.75CUFT; 24K; 255/764-TA; RT8X44; BT14X34 | CVM-RS-TA-.75-764 |
1.0CUFT; 30K; 255/764-TA; RT9X48; BT14X34 | CVM-RS-TA-1.0-764 |
1.5CUFT; 45K; 255/764-TA; RT10X54; BT18X40 | CVM-RS-TA-1.5-764 |
2.0CUFT; 60K; 255/764-TA; RT12X52; BT18X40 | CVM-RS-TA-2.0-764 |
VALUMAX HIGH FLOW 268/740, 268/742, 268/760, 268/762
Standard Features (All Units)
• 25 GPM continuous service flow; 20 GPM maximum backwash
• Soft water refill for a cleaner brine tank
• Quick and simple bypass installation
• Time-tested Duraflow flapper provides frictionless sealing for longer service life
• Fiber-reinforced polymer valve body for superior strength and durability, non-corrosive, and UV-resistant
• Optical sensor for precision cycle positioning
• Designed with double backwash for reduced hardness leakage
• Fully adjustable 5 or 8 cycle control for efficient and reliable water treatment system
• Continuous service flow rate of 25 GPM with a backwash of 20 GPM
• Super capacitor for keeping time of day during power outage
• Programming stored in memory and will not be lost due to power outage
• Large LCD display for easy setup
• History data for valve performance
Valumax 268/740 Logix - Electronic Clock Control | |
Description | Part # |
1.0CUFT; 30K; 268-740; RT 9X48; BT14X34 | CVM-HF-1.0-740 |
1.5CUFT; 45K; 268-740; RT10X54; BT14X34 | CVM-HF-1.5-740 |
2.0CUFT; 60K; 268-740; RT12X52; BT18X40 | CVM-HF-2.0-740 |
3.0CUFT; 90K; 268-740; RT14X65; BT18X40 | CVM-HF-3.0-740 |
Valumax 268/742 Logix - Advanced Electronic Clock Control | |
Description | Part # |
1.0CUFT; 30K; 268-742; RT 9X48; BT14X34 | CVM-HF-1.0-742 |
1.5CUFT; 45K; 268-742; RT10X54; BT14X34 | CVM-HF-1.5-742 |
2.0CUFT; 60K; 268-742; RT12X52; BT18X40 | CVM-HF-2.0-742 |
3.0CUFT; 90K; 268-742; RT14X65; BT18X40 | CVM-HF-3.0-742 |
Valumax 268/760 Logix - Electronic Metered Control | |
Description | Part # |
1.0CUFT; 30K; 268-760; RT9X48; BT14X34 | CVM-HF-1.0-760 |
1.5CUFT; 45K; 268-760; RT10X54; BT14X34 | CVM-HF-1.5-760 |
2.0CUFT; 60K; 268-760; RT12X52; BT18X40 | CVM-HF-2.0-760 |
3.0CUFT; 90K; 268-760; RT14X65; BT18X40 | CVM-HF-3.0-760 |
Valumax 268/762 Logix - Advanced Electronic Metered Control | |
Description | Part # |
1.0CUFT; 30K; 268-762; RT9X48; BT14X34 | CVM-HF-1.0-762 |
1.5CUFT; 45K; 268-762; RT10X54; BT14X34 | CVM-HF-1.5-762 |
2.0CUFT; 60K; 268-762; RT12X52; BT18X40 | CVM-HF-2.0-762 |
3.0CUFT; 90K; 268-762; RT14X65; BT18X40 | CVM-HF-3.0-762 |
Valumax 278/764 Logix Twin (Two sets of install parts required) | |
Description | Part # |
1.0CUFT; 30K; 278/764-TA; RT9X48; BT14X34 | CVM-PCV-1.0-TA |
1.5CUFT; 45K; 278/764-TA; RT10X54; BT18X40 | CVM-PCV-1.5-TA |
2.0CUFT; 60K; 278/764-TA; RT12X52; BT18X40 | CVM-PCV-2.0-TA |
3.0CUFT; 90K; 278/764-TA; RT14X65; BT18X40 | CVM-PCV-3.0-TA |
4.0CUFT; 120K; 278-764 TWIN; RT 16X65; BT 24X40 | CVM-PCV-4.0-TA |
